300-ton Load Capacity Automated Transfer Cart with 5G Remote Control and AI Dynamic Scheduling
Product Details
| Product Name | Battery-Power Transfer Cart | Usage | Heavy Duty Material Transportation |
|---|---|---|---|
| Load Capacity | 1-300ton | Special Function | Anti-Explosion,Heat-Resistant,Lifting,Customized |
| Material | Steel | Transport Package | The Whole Cart Will Be Packed By Tarp. |
| Specification | 2000*2000*500 | Trademark | BETTER |
| Origin | Xinxiang | HS Code | 84289090 |
| Production Capacity | 50 Sets/Month | Dimensions | 2000*2000*500 |
| Drive System | Permanent Magnet Synchronous Wheel Hub Drive | Power Supply | High-power Lithium Batteries Or Lead-acid Batteries |
| Running Speed | 0-25 M/min |
Product Description
Next-Generation High-Throughput Automated Transfer Cart
Product Overview
Designed for intelligent manufacturing factories, large logistics hubs, and high-speed assembly workshops, this new generation high-throughput automatic transfer vehicle integrates 5G remote control, AI dynamic scheduling, and ultra-high-speed heavy-load movement capabilities.
Core Configuration
- Load capacity: 1 - 300 tons
- Drive system: Permanent magnet synchronous wheel hub drive with independent suspension
- Power supply system: High-power lithium batteries or lead-acid batteries
Advanced Safety Features
360° All-Round Perception
Equipped with industrial-grade multi-line laser radar, visual cameras, and ultrasonic radar with integrated perception algorithms for obstacle detection.
Active Flexible Deceleration
Automatically reduces speed and re-plans routes when encountering overturned objects or low obstacles to prevent collisions.
Emergency All-Round Stop
Multiple emergency stop buttons on vehicle body plus remote emergency stop functionality.
Customization Options
- Vehicle Interchange: Supports quick replacement of V-type frames, drum tables, towing hooks, or lifting modules; compatible with sheet materials, pallets, racks, and molds
- Visual Assistance: Optional high-precision pan-tilt camera for long-distance barcode recognition or large workpiece correction assistance
- Environmental Resistance: Optional special versions including explosion-proof, dust-free, and high-temperature heat insulation treatments
Product Parameters
| Model | BXC-2t | BXC-5t | BXC-10t | BXC-16t | BXC-20t | BXC-25t | BXC-30t | BXC-40t | BXC-50t | BXC-63t | BXC-80t | BXC-100t | BXC-150t |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Rated Load (t) | 2 | 5 | 10 | 16 | 20 | 25 | 30 | 40 | 50 | 63 | 80 | 100 | 150 |
| Table Size Length (mm) | 2000 | 3500 | 3600 | 4000 | 4000 | 4500 | 4500 | 5000 | 5500 | 5600 | 6000 | 6500 | 10000 |
| Table Size Width (mm) | 1500 | 2000 | 2000 | 2000 | 2200 | 2200 | 2200 | 2500 | 2500 | 2500 | 2600 | 2800 | 3000 |
| Table Size Height (mm) | 450 | 500 | 500 | 550 | 550 | 600 | 600 | 650 | 650 | 700 | 800 | 900 | 1200 |
| Wheel Base (mm) | 1200 | 2500 | 2600 | 2800 | 2800 | 3200 | 3200 | 3800 | 4200 | 4300 | 4700 | 4900 | 7000 |
| Rail Inner Gauge (mm) | 1200 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1800 | 2000 | 2000 |
| Wheel Diameter (mm) | 270 | 270 | 300 | 350 | 350 | 400 | 400 | 500 | 500 | 600 | 600 | 600 | 600 |
| Wheel Quantity | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 8 |
| Ground Clearance (mm) | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 75 | 75 | 75 | 75 |
| Running Speed (m/min) | 0-25 | 0-25 | 0-25 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-18 |
| Total Power (kw) | 2 | 3 | 2.2 | 2.2 | 2.2 | 3 | 3.5 | 4 | 5 | 6.3 | 8 | 10 | 15 |
| Battery Capacity (Ah) | 150 | 180 | 180 | 200 | 220 | 220 | 260 | 300 | 330 | 400 | 400 | 440 | 600 |
| Battery Voltage (V) | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 72 | 72 | 72 |
| Running Time When Full Load (hrs) | 4.32 | 5.4 | 4.8 | 4.3 | 4 | 4 | 3.5 | 3.6 | 3.3 | 3 | 3.6 | 3.2 | 2.9 |
| Running Distance for One Charge (km) | 6.5 | 8.1 | 7.2 | 5.1 | 4.8 | 4.8 | 4.2 | 4.3 | 4 | 3.6 | 4.3 | 3.8 | 3.2 |
| Max Wheel Load (KN) | 14.4 | 25.8 | 42.6 | 64.5 | 77.7 | 94.5 | 110.4 | 142.8 | 174 | 221.4 | 278.4 | 343.8 | 265.2 |
| Recommended Rail Model | P15 | P18 | P18 | P24 | P24 | P38 | P38 | P43 | P43 | P50 | P50 | QU100 | QU100 |
Application Scenarios
- New Energy Vehicle Assembly: Rapid transportation of battery packs and front/rear axles in coordination with high-speed production lines
- Large-Scale E-commerce/Express Delivery Hubs: Automated transfer of heavy pallets after cross-belt sorting replacement for pre-sorting and collection
- Construction Machinery/Aerospace Component Processing: High-speed cross-process transfer of large structural components within hundred-meter workshops
- Cold Chain Logistics: Efficient handling of entire pallet entry and exit in conjunction with automated rack storage
Customization Inquiry
How can Transfer Carts be customized?
Please provide the following information:
- What load or product will be transferred onto the cart?
- What is the weight of the heaviest lift or load?
- What are the dimensions? (Length; Width; Height)
- What is the trip time and frequency? (# of Trips per shift, Shifts per day)
- What is the travel area you need to cover? (Rail/cement floor, Indoor/Outdoor, straight line travel, etc.)
- What is the distance to travel?
- Other relevant information or using conditions
Our Advantages
Low Noise Operation
Causes low noise level for improved working environment.
Maximum Safety
Offers guarantee of maximum safety for operators and materials handled.
Easy Operation
These vehicles are easy to drive and operate with minimal training required.
Easy Implementation
Operates on standard floors without requiring complex or permanent installation.
Suitable for All Weights
Superb for handling both small and extremely huge loads with payloads up to 300 tons per trolley.
Packaging & Shipping
Our transfer carts are carefully packaged and shipped according to their dimensions:
- For length less than 6m and width less than 2.2m: Transported by 20ft container
- For length between 5.9m and 12m: Transported by 40ft container
- Multiple units (2-3 sets) can be transported by full container
- Single units can be transported by LCL Container
- For widths beyond 2.2m: Transported by flat rack (20 or 40 ft)
- Oversized equipment beyond standard dimensions shipped as bulk cargo
Certifications
