Emission Free Electric Straddle Carrier For Material Transfer In Workshops Industrial Terminals
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Straddle Carrier | Usage | Heavy Duty Material Transportation |
|---|---|---|---|
| Load Capacity | 1-300ton | Special Function | Anti-Explosion,Heat-Resistant,Lifting,Customized |
| Control Mode | Remote Control, Ground Control Panel | Safety Devices | Audio-visual Alarm, Anti-collision Bumper, Emergency Stop Button |
| Application Scenario | Internal Workshop Transport, Production Line Feeding | Customization Options | Customizable Load, Size |
| Material | Steel | Color | Customized |
| Highlight | Emission Free straddle carrier,Electric straddle carrier,Material Transfer electric straddle carrier |
||
Product Description
Emission-free Electric Straddle Carrier for Material Transfer in Workshops and Industrial Terminals
1.Introduction
The Emission-free Electric Straddle Carrier is a sustainable and efficient material handling solution designed for workshops and industrial terminals. It operates by straddling and lifting heavy loads—such as containers, large equipment, or palletized goods—and transporting them with high flexibility across the facility. Powered entirely by electricity, it produces zero on-site emissions and operates quietly, making it ideal for both indoor and outdoor use while supporting environmental goals. This carrier significantly enhances logistical efficiency, optimizes space utilization in confined areas, reduces operational costs, and promotes safer, cleaner material transfer in modern industrial settings like manufacturing plants, logistics hubs, and ports.
2.Application
Manufacturing workshops: In large assembly workshops such as those for automobiles and aircraft manufacturing, oversized components like engines and wings are transported across to achieve flexible workstation distribution.
Logistics and warehousing center: Seamless operation within the rack aisles of the three-dimensional warehouse, directly completing the stacking, picking and placing, and handling of palletized goods, improving the utilization rate of space.
Port and railway freight yards: Preparations for short-distance transportation, stacking and loading of standard containers, large wooden crates or coil steel within the site.
Papermaking and coil industry: Safely and efficiently handle and store large paper rolls, fabric rolls or steel rolls to avoid the risk of deformation caused by hoisting.
Large-scale building materials markets and storage yards: Rapid transfer and organization of bulk building materials such as stone, slabs, and glass to enhance the turnover efficiency of the site.
3.Parameter
| Model | BXC-2t | BXC-5t | BXC-10t | BXC-16t | BXC-20t | BXC-25t | BXC-30t | BXC-40t | BXC-50t | BXC-63t | BXC-80t | BXC-100t | BXC-150t | |
| Rated Load(t) | 2 | 5 | 10 | 16 | 20 | 25 | 30 | 40 | 50 | 63 | 80 | 100 | 150 | |
| Table Size (mm) | Length(L) | 2000 | 3500 | 3600 | 4000 | 4000 | 4500 | 4500 | 5000 | 5500 | 5600 | 6000 | 6500 | 10000 |
| Width(W) | 1500 | 2000 | 2000 | 2000 | 2200 | 2200 | 2200 | 2500 | 2500 | 2500 | 2600 | 2800 | 3000 | |
| Height(H) | 450 | 500 | 500 | 550 | 550 | 600 | 600 | 650 | 650 | 700 | 800 | 900 | 1200 | |
| Wheel Base(mm) | 1200 | 2500 | 2600 | 2800 | 2800 | 3200 | 3200 | 3800 | 4200 | 4300 | 4700 | 4900 | 7000 | |
| Rail Inner Gauge(mm) | 1200 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1800 | 2000 | 2000 | |
| Wheel Diameter (mm) | 270 | 270 | 300 | 350 | 350 | 400 | 400 | 500 | 500 | 600 | 600 | 600 | 600 | |
| Wheel Quantity | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 8 | |
| Ground Clearance(mm) | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 75 | 75 | 75 | 75 | |
| Running Speed (m/min) | 0-25 | 0-25 | 0-25 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-18 | |
| Total Power(kw) | 2 | 3 | 2.2 | 2.2 | 2.2 | 3 | 3.5 | 4 | 5 | 6.3 | 8 | 10 | 15 | |
| Battery Capacity(Ah) | 150 | 180 | 180 | 200 | 220 | 220 | 260 | 300 | 330 | 400 | 400 | 440 | 600 | |
| Battery Voltage(V) | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 72 | 72 | 72 | |
| Running Time When Full Load | 4.32 | 5.4 | 4.8 | 4.3 | 4 | 4 | 3.5 | 3.6 | 3.3 | 3 | 3.6 | 3.2 | 2.9 | |
| Running Distance for One Charge(km) | 6.5 | 8.1 | 7.2 | 5.1 | 4.8 | 4.8 | 4.2 | 4.3 | 4 | 3.6 | 4.3 | 3.8 | 3.2 | |
| Max Wheel Load(KN) | 14.4 | 25.8 | 42.6 | 64.5 | 77.7 | 94.5 | 110.4 | 142.8 | 174 | 221.4 | 278.4 | 343.8 | 265.2 | |
| Recommended Rail Model | P15 | P18 | P18 | P24 | P24 | P38 | P38 | P43 | P43 | P50 | P50 | QU100 | QU100 | |
4.Manufacturing process of warehouse transportation vehicle
5.Product Details
6.Packaging&Shipping
7.FAQ
How can Transfer Carts be customized?
Please tell us:
What load or product will be transferred onto the cart?
What is the weight of the heaviest lift or load?
What are the dimensions? (Length; Width ; Height)
What is the trip time and frequency? (# of Trips per , Shifts per day:)
What is the travel area you need to cover? (Rail/cement floor, Indoor/Outdoor, straight line travel, etc)
What is the distance to travel?
Other relevant information or using condition.
8.Certifications
9.Other products we can offer
10.Customers' Visit
