Trackless Transfer Cart with High Capacity Batteries, Advanced Control Systems, and 1-1500 Tons Load Capacity for Heavy Duty Transport
Product Details
| Product Name | Heavy Load Transport Cart | Usage | Heavy Duty Material Transportation |
|---|---|---|---|
| Application | Steel Industry, Factory, Warehouse, Port | Material | Steel |
| Load Capacity | 1-1500 Tons | Control Mode | Pendant/Remote/PLC Control |
| Transport Package | Other | Trademark | BETTER |
| Origin | China | HS Code | 84289090 |
| Running Speed | 0-25 M/min | Battery Capacity | 150-600 Ah |
| Battery Voltage | 48-72 V | Max Wheel Load | 14.4-343.8 KN |
Product Description
Trackless Transfer Cart Electric Vehicle
The Battery-Powered Trackless Transfer Cart delivers flexible and eco-friendly material transport solutions for modern industrial facilities. Engineered with high-capacity lithium batteries and intelligent energy management systems, it provides extended operational runtime with zero localized emissions. Its rail-free design allows seamless navigation through dynamic workshop layouts, warehouses, and assembly areas without infrastructure constraints. Equipped with robust motors and precision controls, the cart ensures smooth acceleration and accurate positioning for heavy or delicate loads. Advanced safety features including obstacle detection and regenerative braking further enhance operational reliability. Ideal for automating logistics in manufacturing plants, distribution centers, and processing facilities, this cart combines sustainability with high-performance material handling.
Technical Specifications
| Model | BXC-2t | BXC-5t | BXC-10t | BXC-16t | BXC-20t | BXC-25t | BXC-30t | BXC-40t | BXC-50t | BXC-63t | BXC-80t | BXC-100t | BXC-150t |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Rated Load (t) | 2 | 5 | 10 | 16 | 20 | 25 | 30 | 40 | 50 | 63 | 80 | 100 | 150 |
| Table Size Length (mm) | 2000 | 3500 | 3600 | 4000 | 4000 | 4500 | 4500 | 5000 | 5500 | 5600 | 6000 | 6500 | 10000 |
| Table Size Width (mm) | 1500 | 2000 | 2000 | 2000 | 2200 | 2200 | 2200 | 2500 | 2500 | 2500 | 2600 | 2800 | 3000 |
| Table Size Height (mm) | 450 | 500 | 500 | 550 | 550 | 600 | 600 | 650 | 650 | 700 | 800 | 900 | 1200 |
| Wheel Base (mm) | 1200 | 2500 | 2600 | 2800 | 2800 | 3200 | 3200 | 3800 | 4200 | 4300 | 4700 | 4900 | 7000 |
| Rail Inner Gauge (mm) | 1200 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1800 | 2000 | 2000 |
| Wheel Diameter (mm) | 270 | 270 | 300 | 350 | 350 | 400 | 400 | 500 | 500 | 600 | 600 | 600 | 600 |
| Wheel Quantity | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 8 |
| Ground Clearance (mm) | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 75 | 75 | 75 | 75 |
| Running Speed (m/min) | 0-25 | 0-25 | 0-25 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-18 |
| Total Power (kw) | 2 | 3 | 2.2 | 2.2 | 2.2 | 3 | 3.5 | 4 | 5 | 6.3 | 8 | 10 | 15 |
| Battery Capacity (Ah) | 150 | 180 | 180 | 200 | 220 | 220 | 260 | 300 | 330 | 400 | 400 | 440 | 600 |
| Battery Voltage (V) | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 72 | 72 | 72 |
| Running Time When Full Load (hrs) | 4.32 | 5.4 | 4.8 | 4.3 | 4 | 4 | 3.5 | 3.6 | 3.3 | 3 | 3.6 | 3.2 | 2.9 |
| Running Distance for One Charge (km) | 6.5 | 8.1 | 7.2 | 5.1 | 4.8 | 4.8 | 4.2 | 4.3 | 4 | 3.6 | 4.3 | 3.8 | 3.2 |
| Max Wheel Load (KN) | 14.4 | 25.8 | 42.6 | 64.5 | 77.7 | 94.5 | 110.4 | 142.8 | 174 | 221.4 | 278.4 | 343.8 | 265.2 |
| Recommended Rail Model | P15 | P18 | P18 | P24 | P24 | P38 | P38 | P43 | P43 | P50 | P50 | QU100 | QU100 |
Key Advantages
Easy Operation
These vehicles are easy to drive, so as soon as you get it you will be able to use it to transport your loads. We will support you to make the best out of your heavy load transporter.
No Space Limitations
The steering battery-driven trolley is rather compact and with all the different types of steering: 90 degree, carousel, diagonal, compass and so on. And it can operate even in very narrow spaces.
Suitable for Any Environment
The steering powered trolley is fairly silent, completely environmental and requires nearly no maintenance on account of steering and traction are entirely electric and it is battery-driven. The steering battery powered trolley is also created for use in hazardous occasions.
Adaptable to Various Flooring
Hydraulic auxiliaries, steel beam frame, mechanical oscillation of axles and various available types of wheels make the trolley to work even outdoors, guaranteeing an even load distribution on uneven floors.
Customizable Solutions
The steering battery powered trolley can be customized depending on all customer demands: dimensions, control mode rated load, battery life, superstructures, wheels and many others.
Applications
The cable reel powered transfer cart can be applied in assembly line (ring production line, loop production line), metallurgy industry (steel ladle), warehouse transport, ship industry (maintenance, assemble, container transport), workpiece transport in workshop, lathe transport, steel factory (steel billet, steel plate, steel coil, steel pipe, section steel, steel structure), construction (bridge, simple building, concrete, concrete column), petroleum industry (oil pump, sucker rod and parts), energy (polycrystalline silicon, generator, windmill), chemical industry (electrolytic cell, retort etc), railway (rail maintenance, rail welding, train tractor).
Other Products
Welcome to Henan BETTER Handling Equipment Co., Ltd. Our company is specializing in the Design and Manufacture of transport system to solve every material handling requirement. Our product includes Industrial Trailers, Coils & Die Transfer Cars, Electric Railway Ladle Cart, Scissor Lift Tables, Turntables, Trackless Transfer Cart and many other specialty items.
Factories and Customers
Packing and Shipping
- For length less than 6m and width less than 2.2m: Transported by 20ft container
- For length between 5.9m and 12m: Transported by 40ft container
- For 2-3 sets: Transported by full container
- For 1 set: Transported by LCL Container
- For width beyond 2.2m and length less than 12m: Transported by flat rack (20 or 40 ft)
- For equipment beyond above dimensions: Consider bulk cargo transportation
Certifications
How to Choose a Suitable Electric Driven Car?
Please provide the following information for proper selection:
- Load capacity?
- Table size? (Length; Width; Height)
- What cargo do you use the cart to transfer?
- What is the travel area you need to cover? (Indoor/Outdoor, straight line travel, etc)
- How about the running distance?
- What type(s) of power supply are required?
- Do you need any special functions?
