220 Ton Load Capacity Electric Platform Transfer Cart with Rail Guidance and Anti-Slip Platform
Product Details
| Product Name | Battery-Power Transfer Cart | Usage | Heavy Duty Material Transportation |
|---|---|---|---|
| Load Capacity | 1-300ton | Special Function | Anti-Explosion,Heat-Resistant,Lifting,Customized |
| Material | Steel | Transport Package | The Whole Cart Will Be Packed By Tarp. |
| Specification | 2000*2000*500 | Trademark | BETTER |
| Origin | Xinxiang | HS Code | 84289090 |
| Production Capacity | 50 Sets/Month | Table Size | 2000*2000*500 |
| Wheel Diameter | 270-600mm | Running Speed | 0-25m/min |
| Battery Voltage | 48-72V | ||
| Highlight | 220 Ton Load Capacity Electric Platform Transfer Cart,Rail Guidance Compatible Omnidirectional Transfer Cart,Anti-Slip Platform Battery-Powered Transfer Cart |
||
Product Description
220 Ton Heavy Loads Warehouse Transportation Electric Platform Transfer Cart
Product Overview
Designed for large-scale warehouses and logistics centers, this heavy-duty electric cart efficiently handles the transportation of bulky and heavy loads. Its low-profile platform, reinforced structure, and multi-wheel balancing system ensure smooth and precise operation under a 220-ton load.
Compatible with rail guidance, laser navigation, or magnetic strip navigation, the cart supports automated route planning and accurate cargo positioning. The anti-slip platform can be equipped with securing accessories for various heavy goods. With an integrated management system for real-time status and cargo monitoring, it significantly improves warehouse logistics efficiency and safety, making it ideal for storing heavy equipment, building materials, and industrial supplies.
Product Images
Technical Specifications
| Model | BXC-2t | BXC-5t | BXC-10t | BXC-16t | BXC-20t | BXC-25t | BXC-30t | BXC-40t | BXC-50t | BXC-63t | BXC-80t | BXC-100t | BXC-150t |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Rated Load (t) | 2 | 5 | 10 | 16 | 20 | 25 | 30 | 40 | 50 | 63 | 80 | 100 | 150 |
| Table Size Length (mm) | 2000 | 3500 | 3600 | 4000 | 4000 | 4500 | 4500 | 5000 | 5500 | 5600 | 6000 | 6500 | 10000 |
| Table Size Width (mm) | 1500 | 2000 | 2000 | 2000 | 2200 | 2200 | 2200 | 2500 | 2500 | 2500 | 2600 | 2800 | 3000 |
| Table Size Height (mm) | 450 | 500 | 500 | 550 | 550 | 600 | 600 | 650 | 650 | 700 | 800 | 900 | 1200 |
| Wheel Base (mm) | 1200 | 2500 | 2600 | 2800 | 2800 | 3200 | 3200 | 3800 | 4200 | 4300 | 4700 | 4900 | 7000 |
| Rail Inner Gauge (mm) | 1200 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1800 | 2000 | 2000 |
| Wheel Diameter (mm) | 270 | 270 | 300 | 350 | 350 | 400 | 400 | 500 | 500 | 600 | 600 | 600 | 600 |
| Wheel Quantity | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 8 |
| Ground Clearance (mm) | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 75 | 75 | 75 | 75 |
| Running Speed (m/min) | 0-25 | 0-25 | 0-25 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-18 |
| Total Power (kw) | 2 | 3 | 2.2 | 2.2 | 2.2 | 3 | 3.5 | 4 | 5 | 6.3 | 8 | 10 | 15 |
| Battery Capacity (Ah) | 150 | 180 | 180 | 200 | 220 | 220 | 260 | 300 | 330 | 400 | 400 | 440 | 600 |
| Battery Voltage (V) | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 72 | 72 | 72 |
| Running Time When Full Load | 4.32 | 5.4 | 4.8 | 4.3 | 4 | 4 | 3.5 | 3.6 | 3.3 | 3 | 3.6 | 3.2 | 2.9 |
| Running Distance for One Charge (km) | 6.5 | 8.1 | 7.2 | 5.1 | 4.8 | 4.8 | 4.2 | 4.3 | 4 | 3.6 | 4.3 | 3.8 | 3.2 |
| Max Wheel Load (KN) | 14.4 | 25.8 | 42.6 | 64.5 | 77.7 | 94.5 | 110.4 | 142.8 | 174 | 221.4 | 278.4 | 343.8 | 265.2 |
| Recommended Rail Model | P15 | P18 | P18 | P24 | P24 | P38 | P38 | P43 | P43 | P50 | P50 | QU100 | QU100 |
Applications
- Warehousing and logistics for super-heavy goods: In special heavy-duty warehouses (such as steel warehouses and equipment warehouses), responsible for the entry and exit of 220-ton class overweight goods and relocation within the warehouse.
- Large-span warehouse cross-regional transfer: With stable electric platform drive, achieves efficient and reliable transfer of overweight goods between different functional areas within large warehouses.
- Connection of heavy cargo loading and unloading points: Drives directly to loading platforms, precisely connects with hoisting equipment or trucks, and completes rapid loading/unloading of overweight goods.
How can Transfer Carts be customized?
Please provide the following information:
- What load or product will be transferred onto the cart?
- What is the weight of the heaviest lift or load?
- What are the dimensions? (Length; Width; Height)
- What is the trip time and frequency? (# of Trips per, Shifts per day)
- What is the travel area you need to cover? (Rail/cement floor, Indoor/Outdoor, straight line travel, etc)
- What is the distance to travel?
- Other relevant information or using conditions
Low noise: Operates with minimal noise levels for improved working environment.
Maximum safety: Offers guarantee of maximum safety for operators and materials handled.
Easy operation: User-friendly design allows immediate operation with minimal training.
Easy implementation: Operates on standard floors without complex or permanent installation requirements.
Suitable for all weights: Modular fabrication supports handling of both small and extremely large loads up to 300 tons.
Packaging & Shipping
For equipment with length less than 6m and width less than 2.2m: Transported by 20ft container.
For length between 5.9m and 12m: Transported by 40ft container.
Multiple units (2-3 sets): Transported by full container.
Single unit: Available via LCL Container shipping.
For width beyond 2.2m: Requires flat rack transportation (20 or 40 ft).
Oversized equipment: Bulk cargo shipping available.
