270-ton Heat-Resistant Trackless Transfer Cart and Electric Transfer Cart with Anti-Explosion Design for Foundries
Product Details
| Product Name | Battery-Power Transfer Cart | Usage | Heavy Duty Material Transportation |
|---|---|---|---|
| Load Capacity | 270 Tons | Special Function | Anti-Explosion,Heat-Resistant,Lifting,Customized |
| Material | Steel | Transport Package | The Whole Cart Will Be Packed By Tarp. |
| Specification | 2000*2000*500 | Trademark | BETTER |
| Origin | Xinxiang | HS Code | 84289090 |
| Production Capacity | 50 Sets/Month | Table Size | 2000×2000×500 Mm |
| Running Speed | 0-18 M/min | Battery Voltage | 72 V |
| Total Power | 15 KW | Wheel Quantity | 8 |
| Highlight | 270-ton Trackless Transfer Cart,Heat-Resistant Electric Transfer Cart,Anti-Explosion Trackless Transfer Cart |
||
Product Description
Product Overview
The 270-ton Electric Cart is a heavy-duty, heat-resistant solution engineered for extreme environments in furnaces, foundries, and steel mills. Constructed with advanced heat-resistant alloys and thermal shielding, it maintains structural integrity and operational reliability while transporting molten metal, slag, or high-temperature ingots. Its powerful electric drive system ensures zero-emission performance under full load, even in sustained high-temperature conditions. The cart's robust multi-axle design provides exceptional stability for precise positioning of ultra-heavy loads, while integrated cooling systems and fail-safe brakes enhance safety in critical processes. Built to endure thermal stress and abrasive surroundings, this cart optimizes productivity and safety in the most demanding metallurgical and industrial settings.
Detailed Photos
Product Parameters
| Model | BXC-2t | BXC-5t | BXC-10t | BXC-16t | BXC-20t | BXC-25t | BXC-30t | BXC-40t | BXC-50t | BXC-63t | BXC-80t | BXC-100t | BXC-150t |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Rated Load (t) | 2 | 5 | 10 | 16 | 20 | 25 | 30 | 40 | 50 | 63 | 80 | 100 | 150 |
| Table Size — Length L (mm) | 2000 | 3500 | 3600 | 4000 | 4000 | 4500 | 4500 | 5000 | 5500 | 5600 | 6000 | 6500 | 10000 |
| Table Size — Width W (mm) | 1500 | 2000 | 2000 | 2000 | 2200 | 2200 | 2200 | 2500 | 2500 | 2500 | 2600 | 2800 | 3000 |
| Table Size — Height H (mm) | 450 | 500 | 500 | 550 | 550 | 600 | 600 | 650 | 650 | 700 | 800 | 900 | 1200 |
| Wheel Base (mm) | 1200 | 2500 | 2600 | 2800 | 2800 | 3200 | 3200 | 3800 | 4200 | 4300 | 4700 | 4900 | 7000 |
| Rail Inner Gauge (mm) | 1200 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1800 | 2000 | 2000 |
| Wheel Diameter (mm) | 270 | 270 | 300 | 350 | 350 | 400 | 400 | 500 | 500 | 600 | 600 | 600 | 600 |
| Wheel Quantity | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 8 |
| Ground Clearance (mm) | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 75 | 75 | 75 | 75 |
| Running Speed (m/min) | 0–25 | 0–25 | 0–25 | 0–20 | 0–20 | 0–20 | 0–20 | 0–20 | 0–20 | 0–20 | 0–20 | 0–20 | 0–18 |
| Total Power (kW) | 2 | 3 | 2.2 | 2.2 | 2.2 | 3 | 3.5 | 4 | 5 | 6.3 | 8 | 10 | 15 |
| Battery Capacity (Ah) | 150 | 180 | 180 | 200 | 220 | 220 | 260 | 300 | 330 | 400 | 400 | 440 | 600 |
| Battery Voltage (V) | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 72 | 72 | 72 |
| Running Time at Full Load (h) | 4.32 | 5.4 | 4.8 | 4.3 | 4 | 4 | 3.5 | 3.6 | 3.3 | 3 | 3.6 | 3.2 | 2.9 |
| Running Distance per Charge (km) | 6.5 | 8.1 | 7.2 | 5.1 | 4.8 | 4.8 | 4.2 | 4.3 | 4 | 3.6 | 4.3 | 3.8 | 3.2 |
| Max Wheel Load (kN) | 14.4 | 25.8 | 42.6 | 64.5 | 77.7 | 94.5 | 110.4 | 142.8 | 174 | 221.4 | 278.4 | 343.8 | 265.2 |
| Recommended Rail Model | P15 | P18 | P18 | P24 | P24 | P38 | P38 | P43 | P43 | P50 | P50 | QU100 | QU100 |
Production Process
Application
Safe and Reliable Transport of Extremely High-Temperature Materials
With a super-strong load capacity of 270 tons and a dedicated heat-resistant material design, the cart can penetrate deep into high-temperature core areas, safely receiving and transporting extremely hot materials such as hot steel ingots, molten metal ladles, and large castings.
Continuous and Stable Operation Under High-Temperature Conditions
Key components adopt special thermal protection and cooling technologies to ensure that the power, control, and braking systems remain highly reliable even in the harsh environment of continuous exposure to radiant heat and intermittent splash baking.
Optimized Logistics for High-Risk Process Flows
As a high-temperature logistics link connecting smelting furnaces, holding pits, continuous casting machines, or rolling lines, the cart enables precise and efficient flow of heavy-load hot materials between key process points, significantly reducing the risks of manual operations.
Enhanced Control and Safety for Heavy-Load, High-Temperature Transport
Even when carrying full-load hot materials, the advanced electric drive and control system ensures smooth start and stop as well as precise vehicle alignment, effectively preventing operational vibration and overturning risks while comprehensively enhancing operational safety.
FAQ
How can transfer carts be customized?
Please tell us the following details so we can tailor the cart to your needs:
- What load or product will be transferred onto the cart?
- What is the weight of the heaviest lift or load?
- What are the dimensions? (Length, Width, Height)
- What is the trip time and frequency? (Number of trips per shift, shifts per day)
- What is the travel area you need to cover? (Rail or cement floor, indoor or outdoor, straight-line travel, etc.)
- What is the distance to travel?
- Any other relevant information or operating conditions.
Our Advantages
- Low Noise — The cart causes low noise levels during operation.
- Maximum Safety — Offers a guarantee of maximum safety for operators and for the material handled. We truly care about the safety of everyone involved in the job.
- Easy Operation — These vehicles are easy to drive, so as soon as you receive it you will be able to use it to transport your loads. We will support you to make the best out of your heavy-load transporter.
- Easy to Implement into Manufacturing Processes — Operates on standard floors; does not require complex or permanent installation.
- Suitable for All Kinds of Weight — The steering battery-powered trolley is superb for handling both small and extremely huge loads thanks to its modular fabrication and high payloads: up to 300 tons per trolley.
Packaging & Shipping
If the length is less than 6 m and the width is less than 2.2 m, the cart will be transported by 20 ft container. If the length is longer than 5.9 m and less than 12 m, it will be transported by 40 ft container. If the quantity is 2 or 3 sets, they can be transported by full container. If the quantity is 1 set, it can be transported by LCL container.
If the length is less than 12 m and the width exceeds 2.2 m, the cart needs to be transported by flat rack (20 or 40 ft). If the equipment exceeds the above dimensions, the quantity must be considered for bulk cargo.
